最大電圧: 250VAC Maximum current 3A Output normally open or normally closed optional (SPDT) P set value of differential pressure / return difference 10-100kpa P return difference 3-7kpa Maximum allowable static pressure: 14 bar 最大許容差圧 14 bar 作業介質:オイル/水/空気 (注文時に他の介質を指定してください) 作業温度 - 20 °C ~ 93 °C 設定点 繰り返しの偏差 ± 1%: IP54 Connector 1 / 4 "SAE (7 / 16" - 20unf) position A proper pressure measuring position of the differential pressure switch is very important to ensure the accuracy of the pressure difference measurement value and avoid the blockage of the connecting pipe of the differential pressure switch. 必要に応じて,圧力のタップを水流の方向に沿ってパイプの上部に置き,圧力のタップのブロックを避けるために60メガネのフィルタースクリーンを設定します.フィルターの入口と出口に近いようにしてください.図5に示されているように,HVAC熱交換器と液体ポンプが圧力のタップとして使用されます. The installation position of the differential pressure switch shall be considered to avoid the connection copper pipe of the differential pressure switch from frost crack when the outdoor temperature is low in winter必要な場合,水管と差圧スイッチを接続する銅殻を隔離し,電気加熱線を追加します.溶接 1 / 4 "SAEインターフェース圧差スイッチをブロックするために下水フィルターに不浄物を使用しないように,パイプに広がる銅管は,好ましくは,水の流れの方向に沿って90でなければならない.調整可能な差圧スイッチは,直接接続ボックス内の端末ブロックに出力されます.ユーザは自分のアプリケーションに従って内部接続と外部接続を実行できます接続ボックスには,適切なケーブルと1/2"NPTケーブルの防水接続器も用意する必要があります.差圧スイッチの出力接触は,3aの電流抵抗負荷を通過させられる.1a の誘導負荷.
